Japan - Experiment thickness selection machine
TWL05C-T Experimental Thickness Spectrometer is an instrument for detecting debris content in rough rice (white rice) and premature particles in rough rice

Japanese Society (Satake) instrument

1. Combining traditional mills of shredded rice and test particle thickness graders, which have two machine functions that can be used separately.

2. Rice may be sifted with a US-type sifter, rice sift with a S-type sift, and can be easily replaced.

Sieve networks of different sizes of three or more hours meet a variety of customer needs, are highly selective and operate with ease of learning.

产品咨询
适用范围
The TWL05C-T experimental thickness selection machine is an instrument to detect the content of shredded rice in rough rice (white rice) and premature particles in rough rice. You can simulate the process performance of the real machine and evaluate the shredding properties of millet processing using a physical method.
产品特点
Combining the traditional shredded rice separator with the test particle thickness grader, one machine has the capability of two machines, which can be used separately.
It is possible to use a US-type screening net for different types of particles, and a S-type screening net for rice, which can be easily replaced.
The multiple-hour sifting network meets the diverse needs of clients, is highly selective and is simple to learn from.
技术参数
Processing capacity
600g/min (heat selection), 100g/min (long selection)
Transfers
70 rpm (heat selection), 28 rpm (long selection)
Full power.
AC220±10V(50/60Hz)/ 40W
Outer Size
(Long x width x high) 741 x width 455 x height 420 mm
Sieve size available (user-selected)
1.20, 1.40, 1.60, 1.65, 1.70, 1.75, 1.80, 1.85, 1.90, 2.0, 2.10, 2.20, 2.30 length sieve: S3.2, S3.6, S4.0, S4.2, S4.75, S5.2, S5.7, S6.2, S7.0
应用领域
Scrubber rice testing
Rough rice processing
